Description
Flame Tech Water Quenching Heads
Water is provided to quench the work piece as well as cooling the head. Internal threads are provided at the back and at each side of the head for mounting purposes.
| PN | Heating Area Width | Head Size | Number of Flame Ports | Oxygen Flow (CFH) | Fuel Flow (CFH) |
|---|---|---|---|---|---|
| WQ 10 | 1″ | 1 x 2 x 1 3/4″ | 23 | 130–155 | 35–50 |
| WQ 15 | 1 ½” | 1 x 2 x 2 1/4″ | 35 | 200–235 | 50–80 |
| WQ 20 | 2″ | 1 x 2 x 2 3/4″ | 47 | 270–315 | 70–110 |
| WQ 25 | 2 ½” | 1 x 2 x 3 1/4″ | 59 | 340–400 | 80–135 |
| WQ 30 | 3″ | 1 x 2 x 3 3/4″ | 71 | 400–475 | 110–165 |
| WQ 35 | 3 ½” | 1 x 2 x 4 1/4″ | 83 | 475–560 | 125–190 |
| WQ 40 | 4″ | 1 x 2 x 4 3/4″ | 95 | 550–640 | 140–220 |
